90mm Pocket Door Kit

90mm Pocket Door Kit

£144.95

ex. VAT

£173.94

inc. VAT

£173.94

£144.95

ex. VAT

Original inc. VAT price: £173.94

NOW £173.94   £173.94

ALL PRICES ARE SUBJECT TO DELIVERY & VAT

Qty

Trade prices available please call on  03309980617



STUD DOOR PANEL OVERALL DIMS PASSAGE
(WITHOUTJAMBS)
POCKET FINISHED PASSAGE
(INCLUDING JAMB KIT)
FINISHED
WALL
THICKNESS




















89mm CLS
Or
92mm Steel



WIDTH HEIGHT WIDTH HEIGHT WIDTH WIDTH WIDTH HEIGHT





















115mm
DW DH A B C D E F
610 (2'0) 1981 (6'6) 1233 2042 609 624 585 1976
686 (2'3) 1981 (6'6) 1385 2042 685 700 661 1976
711 (2'4) 1981 (6'6) 1434 2042 709 725 685 1976
762 (2'6) 1981 (6'6) 1537 2042 761 776 737 1976
838 (2'9) 1981 (6'6) 1689 2042 837 852 813 1976
914 (3'0) 1981 (6'6) 1841 2042 913 928 889 1976
813 2032 1638 2093 811 827 787 2027
864 2032 1740 2093 862 878 838 2027
626 2040 1264 2101 624 640 600 2035
726 2040 1464 2101 724 740 700 2035
826 2040 1664 2101 824 840 800 2035
926 2040 1864 2101 924 940 900 2035
IMPORTANT ABOVE DIMENSIONS ARE +/-4mm
Installed on finished floor level


This kit is suitable for:

  • 35-44mm thick doors
  • Up to 60 KG in weight per door
  • Fits 89mm CLS studwork or 92mm steel studwork perfectly (for other sizes see stud tab above)
  • 12.5 standard plasterboard
  • DOUBLE DOORS - just order two singles (joining brackets included in each single kit)

This kit includes:

  • All the galvanised steel uprights and horizontals required to build the pocket, plus the track
  • The brackets to fit the frame to the stud work that double as plasterboard positioners and supports
  • Adjustable pocket entrance floor guide
  • Runners with carbon steel 'sealed for life' bearings
  • A spring steel door brake (soft close option available click here)
  • A LIFETIME WARRANTY

Door Jambs / Linings

Order separtely here for 115 or 125 mm finished wall thickness.

What do I need to supply?

  • Door Panel 35 or 44mm thick, max weight 60kg
  • 89mm CLS or 92mm steel studwork
  • Plasterboard

Delivery:

  • Next working day if ordered before 1.30pm for UK mainland (Please note, this is not a guaranteed service and on the odd occasion can take up to two working days).

  • 3-5 Days for Highlands, Channel Islands and Northern Ireland.

  • Please call the office for delivery to EIRE, Northern Ireland, Channel Islands and the Scottish highlands, as this will incur an extra delivery cost.

IMPORTANT DELIVERY INFORMATION

Whilst we are doing all we can to meet our normal delivery lead-times, due to the current unprecedented circumstances, there may be unavoidable exceptions.

Please note: Couriers are currently experiencing delays to their services due to significant increase in volume and reduced staff levels. We'd like to ask all customers to be understanding that there may be some delays with deliveries during these unprecedented times. We're all doing our best to keep things moving, and will do everything we can to help ensure you get the products you need as soon as possible.

Rocket Pocket Door Technical Information

Download Spec Sheet



CHOOSING YOUR ROCKET POCKET DOOR KIT

The Rocket Pocket kit comes in 6 specific sizes, each made for a standard UK door size so you can choose the door you want and it fits first time, every time!!

Max door weight is 60kg which covers most standard doors.  For a double door just buy two singles, they come with a joining bracket completely free of charge with each unit.

So you can choose you door panel size from the table below or if the overall space is the more important factor then find the nearest and you will see what door size you need to purchase.  It's really simple!

WHAT DO YOU GET WITH THE KIT

  • A complete galvanised steel pocket and integral running track, both corrosion resistant.
  • A set of runners each having two 'sealed for life' carbon steel bearing wheel that are contained within the track and cannot 'jump' off the rails.
  • A spring steel braking system is included as standard and brakes the door closure under normal usage.
  • Door brackets to attach the door to the runners, these have the  possibility to adjust up to 7mm so your door can be at the perfect height (remember to always install your frame at finished floor level)
  • Included also are 19mm plasterboard screws for attaching your plasterboard to the framework.  These are important as they are just the right size to attach the board and not protrude too much with the risk of scratching your door.
  • A lifetime warranty against manufacturing and material defects.

So that's it, everything you need to make a door of your choice into a pocket door.  You need only supply the door, plasterboard and any wood linings you choose.

DOUBLE ROCKET POCKET DOORS

Its so easy, each single Rocket Pocket system has an adaptable bracket that ben be used to connect two singles and make them a double so there is no extra cost for a joining kit.  When Installing a double system remember to ensure both systems are perfectly in line and plumb and then the doors will meet exactly in the middle.

double bracket

Installation

Resources to help you with installing your sliding pocket door kit

Take a look at this Rocket Pocket Door video clip below or download our installation instructions to help you with installing your pocket door. The instructions include a list of tools you will require. View the video or scroll down to see how you create the linings.

DOWNLOAD 90MM FRAME INSTALLATION INSTRUCTIONS

DOWNLOAD POCKET DOOR INSTRUCTIONS FOR A GLASS DOOR

DOWNLOAD JAMBS FOR SINGLE DOOR

DOWNLOAD JAMBS FOR DOUBLE DOOR

"The builder who put it together said it was straightforward to do. He's not done something like this before, and found the instructions and video quite helpful!" - feedback from a happy customer.



STUD SIZES

See the table below for recommendations.

sizes graph

DOWNLOAD HERE AS A PDF
